Orange Pi Zero
Orange Pi Zero is an ultra-compact single-board computer built on the Allwinner H2+ quad-core ARM Cortex-A7 SoC with 256 MB or 512 MB DDR3 RAM in a tiny 48×46 mm footprint. It features integrated 802.11n Wi-Fi and 100 Mbps Ethernet for network connectivity, with MQTT enabling IoT platform integration for telemetry and remote control. A 26-pin and 13-pin GPIO header exposes UART, SPI, I2C, and PWM interfaces for sensors and peripheral modules.
Orange Pi Zero is an ultra-compact single-board computer designed for embedded Linux, IoT, and networking projects. Built around the Allwinner H2+ SoC, it packs quad-core processing, onboard Wi-Fi, 100Mbps Ethernet, and a 26-pin GPIO header into a 48×46mm form factor.
Features
- Allwinner H2+ SoC with quad-core Cortex-A7 CPU @ up to 1.2 GHz
- 256 MB / 512 MB DDR3 SDRAM
- MicroSD / TF card slot for OS storage
- 100Mbps Ethernet (onboard)
- Wi-Fi 802.11 b/g/n (XR819)
- 26-pin GPIO header + 13-pin expansion header
- 1x USB 2.0 Host port
- 1x USB 2.0 OTG port (via expansion board)
- CSI camera connector
- 5V power input via Micro USB
- Compact 48×46mm form factor
Overview
| Parameter | Value |
|---|---|
| SoC | Allwinner H2+ |
| CPU | Quad Cortex-A7 @ up to 1.2 GHz |
| RAM | 256 MB / 512 MB DDR3 |
| Storage | MicroSD / TF card |
| Ethernet | 100Mbps (10/100) |
| Wi-Fi | 802.11 b/g/n (XR819) |
| GPIO | 26-pin + 13-pin expansion header |
| USB | 1x USB 2.0 Host, 1x USB 2.0 OTG |
| Camera | CSI connector |
| Power | 5V via Micro USB |
| Size | 48×46mm |
Device Technical Documentation
Download datasheets and manuals for the Orange Pi Zero
