Udoo x86 Ultra
The UDOO X86 Ultra is a powerful x86 single-board computer featuring an Intel Braswell Celeron N3160 quad-core processor, 8 GB DDR3L RAM, and 32 GB eMMC storage. With an integrated Arduino Leonardo co-processor, Gigabit Ethernet, Wi-Fi 802.11ac, Bluetooth 4.0, 3x USB 3.0, HDMI, and M.2 slot, it runs Windows 10, Linux, and Android natively for IoT and maker applications.
UDOO X86 II is the New PC: the most powerful x86 maker board ever and an Arduino™ Leonardo-compatible platform, all embedded on the same board. On UDOO X86 II you can run all the software available for the PC world, from gaming to video streaming, from graphical editors to professional development platforms, plus all the software or the Arduino™ Leonardo world, including all the sketches, libraries and the official Arduino™ Leonardo IDE. It is based on Quad Core 64-bit new-generation x86 processors made by Intel®, designed for the PC domain. Prodigious processors concentrated in 14 nm, with an amount of energy consumption of 5 or 6 Watt.
Features
- Intel Braswell N3160 SoC (quad-core x86) + Arduino Leonardo co-processor
- 8 GB DDR3L RAM, 32 GB eMMC onboard storage
- Intel HD Graphics 400 GPU
- Gigabit Ethernet, Wi-Fi 802.11 ac, Bluetooth 4.0
- USB 3.0, USB 2.0, PCIe M.2 slot
- HDMI 1.4 and DisplayPort output (up to 4K @ 30 Hz)
- 40-pin GPIO header (Arduino compatible)
Specifications
| Parameter | Value |
|---|---|
| SoC | Intel Braswell N3160 |
| CPU | Quad-core Intel Celeron N3160 @ 2.24 GHz |
| GPU | Intel HD Graphics 400 |
| RAM | 8 GB DDR3L |
| Storage | 32 GB eMMC + M.2 SSD slot + MicroSD card slot |
| Ethernet | Gigabit (10/100/1000) |
| Wi-Fi | 802.11 a/b/g/n/ac (2.4 GHz + 5 GHz) |
| Bluetooth | 4.0 |
| USB | 3x USB 3.0, 1x USB 2.0 |
| Video Output | HDMI 1.4 / DisplayPort (4K @ 30 Hz) |
| GPIO | 40-pin header (Arduino compatible) |
| Power | 12V / 3A (DC jack) |
Device Technical Documentation
Download datasheets and manuals for the UDOO X86
Udoo x86 Ultra Product page Udoo x86 Ultra DatasheetAdd Your Device to the Community
