Orange Pi 4
Orange Pi 4 is a powerful single-board computer built on the Rockchip RK3399 hexa-core SoC (dual Cortex-A72 + quad Cortex-A53) with a Mali-T860MP4 GPU and up to 4 GB LPDDR4 RAM, capable of demanding Linux-based edge computing workloads. It provides dual-band 802.11ac Wi-Fi, Bluetooth 5.0, and Gigabit Ethernet for flexible networking, with MQTT enabling IoT platform integration.
Orange Pi 4 is a powerful single-board computer designed for embedded Linux, multimedia, networking, and edge computing workloads.
Built around the Rockchip RK3399, it combines a hexa-core CPU, 4 GB LPDDR4 memory, onboard eMMC, Gigabit Ethernet, Wi-Fi, Bluetooth, and 4K video output, making it well suited for development environments, home servers, IoT gateways, and custom hardware projects.
Features
- Rockchip RK3399 SoC with dual-core Cortex-A72 and quad-core Cortex-A53 CPUs
- 4 GB LPDDR4 RAM with 16 GB eMMC storage
- Mali-T860 MP4 GPU
- Gigabit Ethernet, Wi-Fi, and Bluetooth
- 1x USB 3.0 port and 2x USB 2.0 ports
- HDMI 2.0a output with 4K video support
- 40-pin GPIO header
- DC power input
Overview
| Parameter | Value |
|---|---|
| SoC | Rockchip RK3399 |
| CPU | Dual Cortex-A72 + Quad Cortex-A53 |
| GPU | Mali-T860 MP4 |
| RAM | 4 GB LPDDR4 |
| Storage | 16 GB eMMC + microSD slot |
| Ethernet | Gigabit (10/100/1000) |
| Wi-Fi | Supported |
| Bluetooth | Supported |
| USB | 1x USB 3.0, 2x USB 2.0 |
| Video Output | HDMI 2.0a (up to 4K) |
| GPIO | 40-pin header |
| Power | DC input |
Device Technical Documentation
Download datasheets and manuals for the Orange Pi 4
