KNX IP Multi IO 580
The Weinzierl KNX IP Multi IO 580 is a universal DIN-rail input/output module for KNX IP building automation, offering 48 freely configurable digital channels usable as binary inputs or outputs. Connected directly via Ethernet/LAN, it supports pulse counting for energy meters, controls lights and blinds, and integrates with ETS 4.2 or higher without requiring KNX TP infrastructure.
The KNX IP Multi IO 580 (48I/O) is a universal binary interface for building control. It provides 48 I/O lines. Each line can be used as binary input as well as binary output. The peripherals can be fed by an external voltage of 24 V⎓. Channels which are configured as inputs can be used to control lights or blinds via the KNX network. They also can be used to count impulses, e.g. as interface for energy meters. Channels which are configured as outputs can directly drive signal LEDs, external coupling relays.
Device Technical Documentation
Download datasheets and manuals for the KNX IP Multi IO 580
